3WAY / 4WAY BALL VALVE
SC-70
3WAY / 4WAY BALL VALVE
| SIZE | d | L | H | D | F | A | B | C | N | M | E | D | W (kgf/cm) |
| 1/4" | 11 | 69.3 | 58 | 132 | 34.7 | 10.35 | 5.35 | 9 | 4 | M5*0.8 | 42 | 12 | 33 |
| 3/8" | 11 | 69.3 | 58 | 132 | 34.7 | 10.35 | 5.35 | 9 | 4 | M5*0.8 | 42 | 12 | 33 |
| 1/2" | 12.5 | 75.7 | 61 | 132 | 38.3 | 10.35 | 5.35 | 9 | 4 | M5*0.8 | 42 | 12 | 33 |
| 3/4" | 16 | 86.6 | 82 | 180 | 44.7 | 13.85 | 6.85 | 11 | 4 | M6*1.0 | 50 | 15 | 50 |
| 1" | 20 | 103 | 87.5 | 180 | 50.8 | 20 | 8.5 | 11 | 4 | M6*1.0 | 50 | 15 | 90 |
| 11/4" | 25 | 118.2 | 93 | 180 | 57.7 | 19.35 | 7.85 | 11 | 4 | M6*1.0 | 50 | 15 | 170 |
| 11/2" | 32 | 125.8 | 104 | 210 | 62.6 | 25.75 | 10.25 | 11 | 4 | M8*1.25 | 70 | 15 | 220 |
| 2" | 38 | 149 | 112 | 225 | 74.3 | 25.25 | 9.75 | 14 | 4 | M8*1.25 | 70 | 18.5 | 380 |
| NO | DRAW NAME | PART NAME | MATERIAL | QTY |
| 1 | 01 | BODY | ASTM A.351 Gr.CF8M | 1 |
| 2 | 02 | CAP | ASTM A.351 Gr.CF8M | 2 |
| 3 | 03 | BALL | ASTM A.351 Gr.CF8M | 1 |
| 4 | 04 | BALL SEATS | PTFE | 1 SETS |
| 5 | 05 | STEM | S.S.316 | 1 |
| 6 | 06 | THRUST WASHER | PTFE | 1 |
| 7 | 07 | END SEALS | PTFE | 2 |
| 8 | 08 | STEM PACKING | PTFE | 1 SETS |
| 9 | 09 | GLAND | S.S.304 | 1 |
| 10 | 10 | HANDLE | S.S.304 | 1 |
| 11 | 11 | WASHER | S.S.304 | 1~4 |
| 12 | 12 | WASHER | S.S.304 | 1 |
| 13 | 13 | HANDLE NUT | S.S.304 | 1 |
| 14 | 14 | CAP | ASTM A.351 Gr.CF8M | 1 |
| 15 | 15 | END SEALS | PTFE | 1 |
| 16 | 16 | STOPPER | S.S.304 | 1 |
| 17 | 17 | SCREW | S.S.304 | 1 |
| 18 | 18 | HANDLE SLEEVE | VINYL GRIP | 1 |
