V2C-2PC
9912-V-2C
V2C-2PC
| NO | PART NAME | MATRIAL | QTY |
| 1 | BODY | ASTM A351 Gr.CF8M | 1 |
| 2 | BALL | ASTM A351 Gr.CF8M | 1 |
| 3 | STEM | ASTM A276 Gr.316 | 1 |
| 4 | SEAT | PTFE | 1 |
| 5 | THRUST WASHER | PTFE | 2 |
| 6 | GLAND PACKING | PTFE | 1 |
| 7 | WASHER | S.S.304 | 2 |
| 8 | SPRING WASHER | S.S.304 | 1 |
| 9 | STEM NUT | S.S.304 | 1 |
| 10 | HANDLE | S.S.304 | 1 |
| 11 | HANDLE SLEEVE | VINYL GRIP | 1 |
| SIZE | d | D | A | L | D2 | H |
| 1 / 4" | 11 | 17 | 88 | 51 | RC 1/4" | 46 |
| 3 / 8" | 12 | 21 | 89 | 51 | RC 3/8" | 47 |
| 1 / 2" | 15 | 24 | 89 | 58.5 | RC 1/2" | 50 |
| 3 / 4" | 20 | 31.5 | 89 | 64 | RC 3/4" | 53 |
| 1" | 22 | 38 | 104 | 74 | RC 1" | 61 |
| 11/4" | 32 | 47 | 122 | 86 | RC 1-1/4" | 67 |
| 11/2" | 38 | 53.5 | 128 | 99 | RC 1-1/2" | 78 |
| 2" | 50 | 66.5 | 160 | 115 | RC 2" | 89 |
