Y-STRAINER 800PSI
800 PSI STAINLESS STEEL Y-STRAINER
Y-STRAINER 800PSI
| NO | PART NAME | MATRIAL | QTY |
| 1 | BODY | ASTM A-351 Gr.CF8M | 1 |
| 2 | SCREEN | SUS 316 12MESH | 1 |
| 3 | GASKET | TEFLON | 1 |
| 4 | BONNET | ASTM A-351 Gr.CF8M | 1 |
| 5 | O-RING | TEFLON | 1 |
| 6 | BLOW OFF | ASTM A-351 Gr.CF8M | 1 |
| SIZE | A | B | H | L |
| 1 / 4" | 11 | 23 | 43 | 65 |
| 3 / 8" | 13 | 23 | 43 | 65 |
| 1 / 2" | 15 | 26 | 43 | 65 |
| 3 / 4" | 20 | 32 | 46.5 | 80 |
| 1" | 25 | 41 | 60 | 90 |
| 11/4" | 32 | 51 | 66.5 | 105 |
| 11/2" | 38 | 57 | 76 | 120 |
| 2" | 50 | 69 | 81 | 141 |
| 2 1/2" | 65 | 87 | 93 | 180 |
| 3" | 80 | 102 | 140 | 200 |
