3WAY / 4WAY BALL VALVE
SC-80
3WAY / 4WAY BALL VALVE
| SIZE | d | L | H | D | F | A | N | M | E | H1 | ISO 5211 | W (Kgf/Cm) |
|
| (1) | (2) | ||||||||||||
| 1/4" | 11 | 75.7 | 64.9 | 9 | 38.3 | 8.2 | 6 | 6 | 132 | 36.8 | F04 | F03 | 33 |
| 42 | 36 | ||||||||||||
| 3/8" | 11 | 75.7 | 64.9 | 9 | 38.3 | 8.2 | 6 | 6 | 132 | 36.8 | F04 | F03 | 33 |
| 42 | 36 | ||||||||||||
| 1/2" | 16 | 86.6 | 71.6 | 9 | 44.7 | 9.0 | 6 | 6 | 132 | 44.1 | F04 | F03 | 50 |
| 42 | 36 | ||||||||||||
| 3/4" | 20 | 103 | 94.3 | 11 | 50.8 | 11.5 | 6 | 7 | 180 | 55.1 | F05 | F04 | 90 |
| 50 | 42 | ||||||||||||
| 1" | 25 | 118.2 | 100 | 11 | 57.7 | 11.5 | 6 | 7 | 180 | 60.7 | F05 | F04 | 170 |
| 50 | 42 | ||||||||||||
| 11/4" | 32 | 125.8 | 115.7 | 14 | 62.6 | 15.1 | 7 | 9 | 225 | 75.2 | F07 | F05 | 220 |
| 70 | 50 | ||||||||||||
| 11/2" | 38 | 149 | 124.9 | 14 | 74.3 | 15.1 | 7 | 9 | 225 | 84.4 | F07 | F05 | 380 |
| 70 | 50 | ||||||||||||
| 2" | 50 | 171.2 | 139 | 17 | 85.6 | 18 | 9 | 11 | 267 | 94.6 | F10 | F07 | 600 |
| 102 | 70 | ||||||||||||
| NO | DRAW NO | PART NAME | MATERIAL | QTY |
| 1 | 01 | BODY | ASTM A351 Gr.CF8M | 1 |
| 2 | 02 | CAP | ASTM A351 Gr.CF8M | 2 |
| 3 | 03 | BALL | ASTM A351 Gr.CF8M | 1 |
| 4 | 04 | BALL SEATS | PTFE | 4/1 SETS |
| 5 | 05 | STEM | S.S.316 | 1 |
| 6 | 06 | THRUST WASHER | PTFE | 1 |
| 7 | 07 | END SEALS | PTFE | 2/1 SETS |
| 8 | 08 | STEM PACKING | PTFE | 1 SETS |
| 9 | 09 | THRUST WASHER | TFM1600 | 1 |
| 10 | 10 | GLAND BUSH | S.S.304 | 1 |
| 11 | 11 | BELLVEILLE WASAER | SUS304-CSP | 2 |
| 12 | 12 | STOP | S.S.304 | 1 |
| 13 | 13 | HANDLE NUT | S.S.304 | 2 |
| 14 | 14 | WASHER | S.S.304 | 1 |
| 15 | 15 | HANDLE | S.S.304 | 1 |
| 16 | 16 | HANDLE SLEEVE | VINYL GRIP | 1 |
| 17 | 17 | STOPPER | S.S.304 | 1 |
| 18 | 18 | SCREW | S.S.304 | 1 |
| 19 | 19 | O-RING | VITON | 1 |
| 20 | 20 | END SEALS | PTFE | 1 |
| 21 | 21 | CAP | ASTM A351 Gr.CF8M | 1 |
