CHECK VALVE 200PSI

Flanged check valve 10K 3"

CHECK VALVE 200PSI

NO. PART NAME MATERLAL Q'y
1 BODY CF8 CF8M 1
2 DISC CF8 CF8M 1
3 LEVER CF8 CF8M 1
4 GASKET 304 316 1
5 NUT 304 316 1
6 COTTER PIN 304 316 1
7 GASKET PTFE 1
8 BONNET CF8 CF8M 1
9 BOLT 304 6
10 HINGE PIN 304 316 1
11 THRUST WASHER PTFE 1
12 BOLT 304 316 1
